Specification of High Frequency Welded (HFW) Finned Tube | |
---|---|
Tube/Pipe Material | Carbon Steel, Stainless Steel, Copper, Inconel, Titanium |
Fin Material | Carbon Steel, Stainless Steel, Copper, Aluminum |
Tube/Pipe OD | 8.0mm ~ 219.1mm |
Fin Type | Solid and Serrated |
Fin Height | 5.0mm – 20mm( 50% of tube OD, up to 80% in special request) |
Fin Thickness | 0.4mm ~ 3.0mm |
Fin per Meter (FPM) | Max. 520 fin (based 0.4t fin) |
Tube Length | Max. 27,000 mm |
Application | – Oil & Gas: ACHE(Air cooled), HVAC, Economizer, Heat exchanger, Air Preheater, Fired Heater – Power plant: HRSG, Nuclear, GGH(Desulfurization) |
Advantage of High Frequency Welded(HFW) Finned Tube vs Embedded Fin (G type) & Extrude Type | |
---|---|
Weldability | High Frequency Welded (HFW) can be applied dissimilar tube and fin welds instead of G-Type and Extrude Type |
Efficiency | Higher heat exchange efficiency, 10% higher than G-Type, 15% higher than Extruded |
Cost Save for Material | Tube material cost saving, 10% for G-type (0.3mm Groove), Much less for Extruded Type |
Flexible Fin Pitch | Smaller and lighter equipment |
Tube Size and Quantity | Minimum 10% reduce tube size and quantity |
Higher Temperature | Applied to higher temperature depend on design temperature |
Strong Durability & Maintenance | Strong durability with welded fin, Easy handling and waterjet washed. |
Macro-Picture of Fin Connection Details | |
---|---|
High Frequency Welded (HFW) Fin |
Embedded Fin (G type) |
